The short answer. A soft starter reduces starting current by controlling voltage at fixed frequency. A VFD controls voltage and frequency throughout the run, providing variable speed and motor-control functions. At a fixed operating speed, compare the soft starter’s starting torque, thermal duty and protection with what the load needs. For variable speed or a drive-specific safety function, select a suitable VFD and its control options. Both device types can offer network diagnostics. Compare the available signals and how they support fault finding.
What Is a Soft Starter Doing That a VFD Is Not?
Both devices sit between the supply and an induction motor, and both exist because a squirrel-cage motor connected straight across the line draws a large current and produces a torque step at the instant of switching. The two of them solve that in different places.
A soft starter controls two or three phases, depending on its design, using thyristors to reduce the applied voltage during acceleration. The supply frequency remains fixed, and the available torque must accelerate the load within the permitted starting time. Many installations bypass the thyristors once the motor is running. Current measurement and motor protection can remain active if the starter and bypass arrangement support them.
A VFD rebuilds the supply. It rectifies the incoming mains to DC, holds it on a capacitor bank, and synthesises a new three-phase output at whatever frequency and voltage the control loop asks for. Because the drive controls frequency, it controls speed. Because it controls the ratio of voltage to frequency, it controls motor flux, which is why a VFD can start a motor at close to rated torque without a current surge. The motor never sees the mains directly, on the way up or afterwards.
That difference decides everything downstream. A soft starter is a starting and stopping device for a motor that will run at one speed. A VFD is a running device that also happens to start well. Ask which of those two things the motor needs before comparing prices.
| Soft starter | VFD | |
|---|---|---|
| What it controls | Voltage during start and stop, at supply frequency | Frequency and voltage, continuously |
| Motor speed when running | Fixed by the supply, on bypass | Whatever the controller commands |
| Starting torque available | At a given slip and fixed frequency, approximately proportional to the square of applied voltage | Determined by the drive mode, motor and current limits; vector control can provide high starting torque |
| What the motor sees at full speed | The mains, through a closed bypass | A synthesised waveform from the drive output |
| During the run | Often bypassed; monitoring and protection depend on the model and circuit | Continuously controls motor voltage and frequency |
How Do DOL, Star-Delta, Soft Starter and VFD Compare on Starting Current?
Starting current is the reason the question exists, so it is worth putting all four methods side by side, because the two in the title are only half the field. Direct-on-line and star-delta are what a soft starter or a VFD usually replaces on an existing machine, and a buyer who has only been shown two options has been shown a narrowed choice.
Direct-on-line connects the motor straight to the supply through a contactor and an overload relay. The motor draws several times its full-load current until it approaches speed, and it produces a torque step that the coupling, the gearbox and whatever is on the shaft all feel. For a small motor on a stiff supply this is fine, and it is the cheapest panel there is.
Star-delta starts the motor with its windings in star, so each winding sees a reduced voltage, then switches to delta once the motor has run up. Starting current and starting torque both fall by the same proportion, which is the catch: a load that needs torque to break away may never reach the changeover speed in star. The changeover itself is a second transient, an open-transition switch between two contactors that the supply and the load both notice.
A soft starter replaces both of those with a controlled ramp. The current limit is a parameter and not a consequence of wiring, the ramp time can be tuned to the load, and the stop can be ramped as well, which matters on a pump where an abrupt stop slams a check valve. What it cannot do is produce more torque than the reduced voltage allows, so the same break-away limitation as star-delta exists, in a gentler and adjustable form.
A VFD starts the motor at low frequency and raises it along the acceleration ramp. Starting torque and current depend on the control mode, motor, load and drive overload rating. Vector control can provide high starting torque, but the drive still has to supply the torque needed to accelerate the inertia within the required time.
| Method | Starting current | Torque at start | Transient the load feels | Speed control | Typical panel content |
|---|---|---|---|---|---|
| Direct-on-line | Full inrush, several times full-load current | Full, applied as a step | A hard mechanical shock at switch-on | None | Contactor and overload relay |
| Star-delta | Reduced in star, then a second surge at changeover | Reduced by the same proportion as the current | Two shocks: switch-on and changeover | None | Main, star and delta contactors, a timer, an overload relay and a second set of motor leads |
| Soft starter | Ramped or current-limited, adjustable | Approximately proportional to voltage squared at a given slip and fixed frequency | A controlled ramp, then a bypass closure | None; fixed speed on bypass | Soft starter, bypass contactor if not internal, line protection |
| VFD | Set by load torque, acceleration time and drive current limits | High starting torque with a suitable control mode and motor | Programmable acceleration within the drive and load limits | Continuous | Drive, line reactor or filter where the supply needs it, screened motor cable, cooling |
The last column is the one that turns into money, and it is covered further down. The fourth column is the one that turns into a maintenance ticket: every hard start is a small hammer blow to the drivetrain, and a machine that starts many times a shift accumulates them.
Does the Load Need Speed Control, or Just a Gentler Start?
The required operating-speed range is the first question. Motor diagnostics and stopping functions also affect the selection, but they need a device-by-device comparison.
The first is that the required speed changes. A conveyor that runs at a different rate per product, a pump that has to deliver a different flow per recipe, an agitator whose speed is a process parameter, a fan whose duty follows the load on the extraction system: each of these needs a speed command, and only a VFD takes one. On the machines we build and modernise, that command comes from the PLC as part of the recipe, so a format change moves the speed without anyone touching the panel.
A VFD can report current, frequency, torque estimates and fault history through its supported interface. A networked soft starter can also provide current, protection status and diagnostics during the run, including bypass where its measurement circuit supports it. Compare the signals and update rates required by the PLC. ABB’s PSTX feature overview illustrates the monitoring available on a soft starter.
Where the motor runs at one speed, a soft starter may meet both the starting and monitoring requirements. A VFD becomes worthwhile when the process needs its speed, torque or stopping functions; include the panel heat and supply-side effects in that comparison.
Slowing a conveyor may also be part of line balancing or accumulation control. Check whether the speed change improves the required flow or merely reduces output to match an unresolved upstream loss. How to distinguish those cases is in our guide to finding where production efficiency is actually being lost.
Where Does the Energy Saving Come From, and When Is There None?
Variable-duty centrifugal pumps and fans are a common energy-saving application for VFDs. Speed reduction can reduce input power compared with throttling at full speed, but the saving depends on the system curve, static head, efficiency and operating hours. Compare the required flow and pressure over the duty cycle before calculating payback.
For other loads, build the energy case from the duty profile. Reduced speed may avoid idle running, throttling, unloading or excess production, while drive losses and reduced throughput work in the other direction. Measure the required output and input energy over the operating cycle to compare the proposed control strategies.
A bypassed soft starter has low running losses because the main motor current bypasses its power semiconductors. Its principal value is the starting behaviour. Compare that with a VFD’s process and energy benefits using the actual load and operating hours.
For pumps and fans, compare the actual operating point with the required flow and pressure. Even a steady duty can benefit from a lower selected speed or an impeller trim if the pump is oversized. Also check low-speed motor cooling: a shaft-mounted fan moves less air as speed falls, and sustained high torque at low speed may require derating or separate cooling.
What Does the Price Difference Between a Soft Starter and a VFD Actually Buy?
A soft starter often has a lower purchase price than a VFD of comparable duty. Include protection, wiring, cooling and controls when comparing the installed motor circuit cost.
A soft starter may include an internal bypass or use an external one. Its panel still needs protection and thermal sizing for the specified start duty. Bypass reduces semiconductor losses during the run; cable selection and EMC measures follow the product instructions and installation.
A VFD brings the drive, a line reactor or a harmonic filter where the supply or the site rules ask for one, a screened motor cable terminated correctly at both ends, an enclosure with enough airflow or a cooling unit to remove the drive’s losses through a Singapore afternoon, and a parameter set that has to be backed up and kept with the machine records. Make those items explicit in the quotation so the drive price and the installed price can be compared.
What that spend buys back is the list from earlier: speed by recipe, starting torque from the selected control mode, network diagnostics and the specified stopping functions, and, with the right option module, a safety function that removes torque from the motor without a contactor in the motor circuit. Where the machine needs those, the drive becomes part of the control and safety architecture, and stops being a box that spins a motor. Where it needs none of them, the same configuration is expensive furniture.
| Criterion | Soft starter | VFD | Which fits, and under what condition |
|---|---|---|---|
| Starting current | Adjustable within the starter rating; reduced voltage also reduces torque | Depends on acceleration torque and the drive overload rating | Compare the load torque curve, starting time and available supply |
| Speed control | None | Continuous, by recipe or by process signal | VFD where speed control is required; other drive functions can also justify it |
| Energy | Low running losses when bypassed | May save through demand-matched operation; the drive also adds losses | Compare input energy for the same useful output over the actual duty cycle |
| Purchase and panel cost | Often lower; check bypass, starting duty and enclosure heat | Include required filters, cable, cooling and parameter management | Compare the complete installed circuit |
| Maintenance and diagnostics | Starter electronics, bypass and protection; signals depend on the model | Power electronics, cooling and parameters; signals depend on the interface | Specify the alarms, measurements and spares the maintenance team needs |
Read the last column as a set of conditions, and never as a scorecard. A motor usually sits clearly on one side or the other once the condition is stated out loud, and the argument only lasts while it is being held at the level of preference.
Which Starter Is Easier to Maintain and Diagnose?
They fail differently, and a maintenance team should know which failure it is signing up for.
A soft starter has thyristors, a control board and, on many units, an internal bypass. Thyristors dislike heat, and the ramp is where the heat is made, so a soft starter on a motor that starts many times an hour is working far harder than the same unit on a motor that starts once a shift. The number of starts per hour is a rating on the unit for that reason, and it belongs on the specification. An unsuccessful start, protection trip or bypass fault needs diagnosis from the starter indications and the motor circuit, using the manufacturer’s test procedure.
A VFD has a DC bus capacitor bank that ages, cooling fans with a service life, and firmware with a version. It also has a parameter set, and a drive replaced from stock without that set loaded is a different machine until somebody finds the backup. Drive failures are more varied: an overvoltage trip on deceleration, an earth fault on a damaged motor cable, a thermal trip on a hot afternoon, a nuisance trip from a parameter nobody documented. The selected drive can expose fault records and measurements, but the PLC mapping and HMI alarm text still have to be configured and tested. How that alarm reaches the operator, and why a drive fault should read as a situation and never as a bare code, is part of our page on what belongs on the machine HMI and what belongs in SCADA.
Check the bypass contactor’s rating and operating sequence separately from the line contactor. In a coordinated soft-starter circuit, current transfers between the thyristors and bypass contacts; the bypass is not necessarily making and breaking full motor current like a DOL contactor. Follow the starter manufacturer’s selection and service instructions. For VFD replacements, retain the drive model, option modules and parameter file. The factory acceptance test for a modernised machine should include a parameter backup and restore check.
Which Loads Take Which Starter?
The load decides. The table lists the loads that appear on the kinds of machines and lines we build and modernise, with the starter that typically fits and the condition that would change the answer.
| Load | Typical fit | What would change it |
|---|---|---|
| Fixed-speed belt or roller conveyor | Soft starter, or DOL on a small motor | A speed that changes per product, or a start-stop cycle frequent enough to wear a contactor and hammer the gearbox |
| Conveyor whose speed is a recipe value | VFD | Nothing; a soft starter cannot deliver the requirement |
| Centrifugal pump or fan with varying flow demand | VFD | A duty that turns out to be fixed, in which case a soft starter and an impeller trim may be cheaper |
| Centrifugal pump at fixed duty with water hammer on stop | Soft starter with a soft-stop ramp | A need to control flow, which moves it to a drive |
| Positive-displacement or dosing pump | VFD where throughput is set by speed; a metering stroke needs its own motion-control selection | A fixed throughput with no recipe, which needs only a starter |
| Agitator or mixer with a process-set speed | VFD | A single fixed speed, then a soft starter for the start torque |
| High-inertia load such as a large drum, centrifuge or flywheel | Compare a suitably rated soft starter and VFD against the acceleration duty | Variable speed, controlled deceleration or a start beyond the soft starter’s thermal rating favours a VFD |
| Extraction fan or dust collection blower on a treatment machine | VFD where extraction is regulated; soft starter where it runs at one speed | Whether anyone will ever adjust it |
| Compressor or hydraulic power unit | Soft starter, with an unloaded start | Multi-stage capacity control, which is usually a packaged decision the compressor maker has already made |
Two rows carry a caveat. The dosing row is there because a dosing pump on a filling line has two different questions in it: how fast the pump turns, which is a drive question, and where the stroke starts and stops, which is a motion-control question, and the second one is settled on our servo and drive retrofit page. The conveyor row is the one that gets a drive it does not need, and on a packaging line with several conveyors in series the difference between a drive on every conveyor and a drive on the one that needs it shows up in the panel, the cabling and the commissioning time; how those conveyors are sequenced and where speed genuinely has to vary between them is on our packaging line integration page.
Which Starter Belongs on a Retrofit, and Who Decides?
On a new machine the choice is made once, in the panel design. On a retrofit it is made against an existing panel, an existing motor and an existing supply, and three things about that situation change the answer.
The existing motor comes first. An induction motor built decades ago was designed for a sine wave from the mains, and the steep voltage edges from a drive output stress its winding insulation in a way the soft starter’s chopped mains does not. Whether that motor can tolerate a drive depends on its insulation class, the cable length and whether an output filter is fitted, and the survey answers that before anyone quotes. A soft starter avoids that drive-output issue, but starting current, acceleration time and the motor’s thermal duty still need checking.
The existing panel comes second. A soft starter may replace a star-delta arrangement with fewer contactors, subject to fit and thermal checks. A VFD installation may need different cabling, filtering and heat removal. Compare reusing the enclosure with replacing it, using the actual losses, ambient temperature and space available.
Third is the control system the motor joins. Choose the drive interfaces for the PLC, feedback and safety functions that the machine actually needs. Standardising compatible drive configurations can simplify spares, but motor ratings, duty and required options may differ. How the safety function is rated and validated, and where the drive’s safety option sits in the performance level calculation, is covered in our guide to machine safety risk assessment and on our machine safety and CE marking page.
Whichever device is selected, IEC 60204-1 provides the machine electrical framework, including isolation, protection, conductor identification, documentation and stop categories. Specify the emergency-stop function separately from the normal ramp. A VFD or soft starter’s ordinary stop setting is not, by itself, a validated safety function; the design must define the stopping sequence, energy removal or holding measures and fault response. For a US-market machine, include the applicable NFPA 79 requirements in that design basis.
| What pulls a motor towards a VFD on a retrofit | What keeps it on a soft starter |
|---|---|
| Its speed is, or is about to become, a recipe value | It runs at one speed and will keep doing so |
| The process needs torque or speed functions, with the required drive signals mapped into the PLC | A compatible soft starter provides the required starting behaviour, protection and monitoring |
| The safety circuit must remove torque without opening a contactor in the motor lead | A safety contactor in the motor circuit is acceptable and already designed |
| The energy case supports demand-matched operation | Fixed-speed operation meets the duty without a demonstrated energy benefit from a drive |
| The motor is drive-rated or will be replaced | The motor is old, unfiltered drive output would stress it, and replacing it is out of scope |
| The panel is being replaced anyway | The panel stays and has neither the space nor the cooling for a drive |
The survey settles it motor by motor, and what it has to establish before a price can exist is set out on our machine retrofit and modernisation page.
When Is Neither Starter the Right Answer?
The motor is small and starts rarely. Direct-on-line with a properly set overload is a complete answer for a small motor that starts a few times a day on a supply that does not notice. Adding a soft starter to it buys a smoother start nobody asked for.
The star-delta starter is working. A machine that has started reliably in star-delta for years, whose load reaches changeover speed every time and whose contactors are in good condition, is not a problem. Replace it when the contactors wear out or when the load changes, not because a newer device exists.
The problem is mechanical. A conveyor that trips its overload on start because a bearing is failing, or a pump that hammers on stop because a check valve is worn, presents as a starter problem and is not one. New electrics will show the fault in better detail and produce the same fault.
The axis needs position. Repeated positioning, profiles or coordinated axes need a motion-control review that covers trajectory and feedback requirements. Servo systems, closed-loop drives and stepper systems serve different accuracy and dynamic requirements; the servo and drive retrofit page linked above covers the retrofit scope.
The equipment is packaged. A compressor set, a chiller or a pump skid from its maker arrives with the starter its maker chose and a controller that expects it. Changing that starter changes who supports the package, and the answer is usually to leave it alone and integrate the package’s signals into the machine.
The machine is being replaced. Where a retrofit survey finds that the mechanics are worn out, the starter question dies with the machine, and the comparison that matters is on our retrofit vs replace page.
Which One Should You Buy?
Compare the complete motor circuit, including protection, starting torque, operating speed, stopping and diagnostics. Then price the panel changes, motor and cable work, commissioning and spares. This gives each motor a defined reason for using a soft starter or VFD and makes the retrofit quotations comparable.
